Bosch PRS-NSP Network Splitter
Manufacturer: Bosch
UPC: 800549242660
Condition: New
Bosch PRS-NSP Network Splitter
Product TypeSignal Splitter
Brand NameBosch
ManufacturerThe Bosch Group
Product NamePRS-NSP Network Splitter
Manufacturer Part NumberPRS-NSP
Manufacturer Website Addresshttp://www.bosch.com
Packaged Quantity1
Weight (Approximate)1.54 lb
Input Voltage56 V DC
Package Contents
  • PRS-NSP Network Splitter
  • 1 x Mounting Bracket
  • 1 x Power Supply Connector
The network splitter is used in a network to provide two branches from the main cable run. It can use an external DC power supply, or it can use the power supply from the network controller. The unit automatically switches to the local power supply unit when it is connected to it, reducing the power drain on the main network. The network splitter can also function as a repeater, effectively extending the length of the main network another 50 meters. Functions The splitter inserts Praesideo units connected to a tapoff into the main network, however without the redundancy of the main loop. The maximum current supplied for each of the two tap-offs is separately selectable. External power from the local supply is used only for the tap-offs, and is not fed into the main system cable. The network splitter has two LEDs for diagnostic purposes. Controls and indicators Power status LED Fault status LED Jumpers to configure tap-offs power behavior Interconnections Two system network connections for main network Two system network connection for network tap-offs External power supply input
