TUF TUF GAMING X570-PRO (WI-F Desktop Motherboard
Manufacturer: TUF
UPC: 192876900321
Condition: New
TUF TUF GAMING X570-PRO (WI-F Desktop Motherboard
Product Type Desktop Motherboard
Brand Name TUF
Manufacturer ASUS Computer International
Product Model GAMING X570-PRO (WI-FI)
Product Name GAMING X570-PRO (WI-FI) Desktop Motherboard
Manufacturer Part Number TUF GAMING X570-PRO (WI-FI)
Manufacturer Website Address http://usa.asus.com
Environmentally Friendly Yes
Environmental Certification RoHS
Package Contents
  • GAMING X570-PRO (WI-FI) Desktop Motherboard
  • User's Manual
  • I/O Shield
  • 2 x SATA 6Gb/s Cable(s)
  • 1 x M.2 Screw Package
  • 1 x Supporting DVD
  • 1 x ASUS 2T2R Dual Band Wi-Fi Moving Antennas (Wi-Fi 802.11a/b/g/n/ac compliant)
  • 1 x TUF GAMING Sticker
  • 1 x TUF Certification Card(s)
  • 1 x M.2 Rubber Package(s)
Chipset Manufacturer AMD
Processor Socket Socket AM4
Processor Supported Ryzen 7 Ryzen 7 PRO Ryzen 5 Ryzen 5 PRO Ryzen 3 Ryzen 3 PRO Ryzen 9 Athlon Athlon PRO
Total Processor Supported 1
Number of Memory Slots 4
Memory Form Factor DIMM UDIMM
Memory Speed Supported 5100 MHz (O.C.) 4800 MHz (O.C.) 4600 MHz (O.C.) 4400 MHz (O.C.) 4266 MHz (O.C.) 4133 MHz (O.C.) 4000 MHz (O.C.) 3866 MHz (O.C.) 3733 MHz (O.C.) 3600 MHz (O.C.) 3466 MHz (O.C.) 3400 MHz (O.C.) 3200 MHz 3000 MHz 2933 MHz 2800 MHz 2666 MHz 2400 MHz 2133 MHz
Memory Technology DDR4 SDRAM
Maximum Memory 128 GB
Audio Channels 7.1
Bluetooth Yes
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11 a/b/g/n/ac/ax
2.5Gigabit Ethernet Yes
Number of SATA Interfaces 8
Total Number of Onboard USB Ports 7
Number of Onboard USB 2.0 Ports 4
Number of M.2 Interfaces 2
Number of Onboard USB 3.2 Ports 3
Number of PCI Express x1 Slots 2
Number of Total Expansion Slots 4
Number of PCI Express x16 Slots 2
Total Number of PCI Express Slots 4
Onboard Video CPU Dependent Video
RAID Supported Yes
RAID Levels 0 1 10
Controller Type Serial ATA/600
Number of Network (RJ-45) Ports 1
DisplayPort Yes
Total Number of USB Ports 7
Number of USB 3.2 Ports 7
Width 12"
Depth 9.6"
Form Factor ATX
Limited Warranty 3 Year
AMD AM4 X570 ATX gaming motherboard with PCIe 4.0, dual M.2, 2.5G Intel LAN, Wi-Fi 6, 14 Dr. MOS power stages, USB 3.2 Gen 2 Type-C ports and Aura Sync RGB lighting AMD AM4 Socket: Ready for 3rd and 2nd Gen AMD Ryzen™/3rd, 2nd and 1st Gen AMD Ryzen™ with Radeon™ Graphics Processors Enhanced Power Solution: 12+2 Dr. MOS power stages, 6-layer PCB, ProCool sockets, military-grade TUF components, and Digi+ VRM for maximum durability Comprehensive Cooling: Active chipset heatsink, VRM heatsink, M.2 heatsink, hybrid fan headers and Fan Xpert 4 Next-Gen Connectivity: Dual PCIe 4.0 M.2 and USB 3.2 Gen 2 Type-A /Type-C Gaming Networking: Exclusive onboard 2.5G Intel® LAN, Intel® WiFi 6, Bluetooth 5.1, TUF LANGuard and TurboLAN technology Realtek S1200A Codec: Pristine audio quality with unprecedented 108dB signal-to-noise ratio for stereo line-out and 103dB SNR for line-in Aura Sync RGB: Synchronize LED lighting with a vast portfolio of compatible PC gear, including addressable RGB strips TUF Gaming Alliance: ASUS hardware ecosystem ensures the best compatibility and complementary aesthetics from components to case DURABLE. STABLE. RELIABLE. TUF Gaming X570-Pro (Wi-Fi) distills the essential elements of the latest AMD platform and combines them with game-ready features and proven durability. Engineered with military-grade components, upgraded power solutions and a comprehensive set of cooling options, these motherboards deliver rock-solid performance with unwavering gaming stability. When you build with a TUF Gaming motherboard, you also benefit from the TUF Gaming Alliance - an ASUS collaboration with trusted industry partners that ensures easier building, the best compatibility, and complementary aesthetics from components to case. ROCK-SOLID PERFORMANCE With upgraded power delivery and comprehensive cooling options to fuel AMD's latest CPUs, plus support for faster memory and storage, TUF Gaming X570-Pro (Wi-Fi) is the perfect foundation for your next high-core-count AMD battle rig. Dr. MOS The TUF Gaming X570-Pro (Wi-Fi)'s CPU VRM utilizes 12+2 Dr. MOS power stages that combine high-side and low-side MOSFETs and drivers into a single package, delivering the power and efficiency that AMD's latest processors demand. 6-LAYER PCB DESIGN Multiple PCB layers shift heat away from critical components, providing more headroom to push your CPUs beyond stock speeds. ProCool Sockets ENHANCED EATX 4-PIN & 8-PIN SOCKETS Solid and more durable Prevent hotspots and connector failure Compared with traditional power inputs, ProCool sockets are built to tight specifications to ensure flush contact with the PSU power lines. This lowers impedance, which helps to prevent hotspots and connector failure. UF COMPONENTSTUF CHOKES Certified military-grade TUF chokes deliver rock-steady power to the CPU, helping to improve system stability. TUF CAPACITORS +20% temperature tolerance and 2.5X-longer lifespan. Digi+ VRM The Digi+ VRM voltage-regulator module (VRM) is one of the finest in the industry, ensuring ultra-smooth and ultra-clean power delivery to the CPU at all times.
