Tripp Lite SUINT3000LCD2UN SmartOnline 3000VA Rack-mountable UPS
Manufacturer: Tripp Lite
UPC: 037332253583
Condition: New
Tripp Lite SUINT3000LCD2UN SmartOnline 3000VA Rack-mountable UPS
Price $2,388.74
Product Type Dual Conversion Online UPS
Brand Name Tripp Lite
Manufacturer Tripp Lite
Product Model SUINT3000LCD2UN
Product Name SmartOnline SUINT3000LCD2UN 3000VA Rack-mountable UPS
Product Line SmartOnline
Manufacturer Part Number SUINT3000LCD2UN
Manufacturer Website Address http://www.tripplite.com
Environmentally Friendly Yes
Environmental Certification RoHS
Energy Star Yes
Package Contents
  • SmartOnline SUINT3000LCD2UN 3000VA Rack-mountable UPS
  • WEBCARDLX Network Interface Card
  • USB Cable
  • RS-232 Cable
  • EPO Cable
  • C19-to-C20 Power Cable
  • 2 x C13-to-C14 Power Cables
  • 4-post Rack-mounting Hardware
  • Owner's Manual
Backup/Run Time (Full Load) 5 Minute
Typical Battery Recharge Time 3 Hour
Transfer Time 0 ns
Receptacles 8 x IEC 60320 C13 2 x IEC 60320 C19
Plug/Connector Type IEC 60320 C20
Height 3.5"
Width 17.2"
Depth 24.3"
Rack Height 2U
Form Factor Rack-mountable
Weight (Approximate) 68.72 lb
Load Capacity 3000 VA/2700 W
Input Voltage 230 V AC
Output Voltage 200 V AC 208 V AC 220 V AC 230 V AC 240 V AC
Limited Warranty 2 Year
Double-Conversion UPS Protects Equipment against Damage, Downtime and Data Loss This 200/208/220/230/240V 50/60 Hz UPS system maintains perfect output by converting AC input to DC, then reconverting UPS output to fully regulated sine wave AC with +/-2% voltage regulation in online and battery modes. Featuring a 2.7kW capacity, high 0.9 power factor, 570 joules of surge suppression, true on-line operation with pure sine wave output and zero transfer time to battery mode in on-line double-conversion mode, the SmartOnline® SUINT3000LCD2UN double-conversion UPS provides the highest level of AC power protection and battery backup for critical network closet, computer room and data center equipment. Set Power Strategies to Reflect Your Protection Priorities Pick your power strategy, from precise power for sensitive systems to the highest possible electrical efficiency, while ensuring 100% uptime. Choose from five selectable strategies: Max Efficiency, Max Quality, Frequency Regulation, Frequency Conversion and Auto Adaptive, which automatically offers increased efficiency when power conditions are good and enhanced power quality when power conditions are poor. Individually Controllable Load Banks Let You Access and Control Outlets Remotely Six C13 and two C19 outlets are split into two switchable load banks, allowing you to reboot select components or shed loads remotely. In addition to those eight outlets, this UPS provides two more C13 outlets in their own unswitched bank for powering critical components. Reliable, Expandable Battery Backup Keeps You Operational Through Power Outages The field-replaceable, hot-swappable internal battery (RBC72S) provides 13.5 minutes of support at half load (1350W) and five minutes at full load (2700W), keeping protected equipment operational through power failures. For mission-critical applications demanding scalable extended runtime, the UPS supports "smart" external battery packs, such as Tripp Lite's BP726V18-2US (sold separately). Both the internal and external batteries are automatically sensed and configured during replacement to offer accurate runtime-remaining and battery age notifications during outages. The intelligent battery management system with temperature-compensated charging extends battery life. Automatic Bypass Maintains Utility Output During Fault Conditions Auto-bypass mode keeps connected equipment powered and operational, even during UPS fault conditions. ENERGY STAR-Certified Economy Mode Helps You Save Money and Protect the Environment By meeting strict EPA efficiency guidelines, this ENERGY STAR-certified UPS system helps you save money and energy. A power-saving Economy mode setting option offers enhanced efficiency and reduced BTU output when utility power is already high quality. Automatically Turns Back On After Power Is Restored Battery-independent restart ensures automatic UPS power-up without user interaction after lengthy power outages, even when batteries are expired and require replacement. Intuitive Front-Panel Interface for Convenient UPS Operation and Monitoring The front-panel LCD screen reports UPS operating mode, detailed UPS status and site-power information, as well as a variety of advanced UPS setup and configuration options. LEDs indicate AC input/output, battery and fault status. Advanced Communications Ports Allow for Automatic Saves and Shutdowns RS-232 and HID-compliant USB ports connect to a computer running Tripp Lite's free downloadable PowerAlert® software to enable safe unattended file saves and system shutdown in case of a prolonged power failure.
