Tripp Lite PDUMVR20NETLX 24-Outlet PDU
Manufacturer: Tripp Lite
UPC: 037332204141
Condition: New
Tripp Lite PDUMVR20NETLX 24-Outlet PDU
Price $1,148.85
Product TypePDU
Brand NameTripp Lite
ManufacturerTripp Lite
Product ModelPDUMVR20NETLX
Product NamePDUMVR20NETLX 24-Outlet PDU
Manufacturer Part NumberPDUMVR20NETLX
Manufacturer Website Addresshttp://www.tripplite.com
Environmentally FriendlyYes
Environmental CertificationRoHS
TAA CompliantYes
Package Contents
  • PDUMVR20NETLX 24-Outlet PDU
  • Built-in LX Platform Interface
  • NEMA 5-20P Plug Adapter
  • Configuration Cable
  • Cord Retention Brackets
  • 24 x Cable Ties
  • Rack-mounting Hardware
  • Mounting Bracket Accessory
  • Owner's Manual
Mounting OrientationVertical
Rack Height0U
Form FactorRack-mountable
Weight (Approximate)9.60 lb
Power Rating (Watt)2030 W
Input Current20 A
Input Voltage120 V AC
Output Voltage100 V AC120 V AC127 V AC
Input ReceptaclesNEMA 5-20PNEMA L5-20P
Output Receptacles24 x NEMA 5-15/20R
  • IPv4
  • IPv6
  • HTTP
  • SMTP
  • SNMPv1
  • SNMPv2
  • SNMPv3
  • telnet
  • SSH
  • FTP
  • DHCP
  • NTP
Limited Warranty2 Year
The PDUMVR20NETLX 1.9kW Single-Phase Switched PDU with individual outlet metering provides advanced network control and remote power monitoring with the ability to turn on, turn off, reboot or lock out power to each outlet. By reducing the frequency of on-site visits, these advanced remote capabilities can save you money and reduce downtime.The switched PDU features 24 individually controllable NEMA 5-15/20R outlets with cord retention brackets to prevent cables from becoming accidentally disconnected. A 10-foot power cord with NEMA L5-20P plug and optional 5-20P adapter connects the PDU to an AC source, generator or protected UPS.The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP.A digital ammeter allows you to monitor each load bank's current, each outlet's current and the total connected PDU load in real time to ensure they remain well below maximum capacity with no danger of overload. The switched PDU mounts in 0U of space in EIA-standard 19-inch racks using the included toolless mounting buttons or the included rack-mounting brackets.
