Tripp Lite PDUMV20HVNETLX 24-Outlet PDU
Manufacturer: Tripp Lite
UPC: 037332205292
SKU: PDUMV20HVNETLX
Condition: New
Tripp Lite PDUMV20HVNETLX 24-Outlet PDU
Price $849.48
Product TypePDU
Brand NameTripp Lite
ManufacturerTripp Lite
Product ModelPDUMV20HVNETLX
Product NamePDUMV20HVNETLX 24-Outlet PDU
Manufacturer Part NumberPDUMV20HVNETLX
Manufacturer Website Addresshttp://www.tripplite.com
Environmentally FriendlyYes
Environmental CertificationRoHS
TAA CompliantYes
Package Contents
  • PDUMV20HVNETLX 24-Outlet PDU
  • Built-in LX Platform Interface
  • Detachable NEMA L6-20P to C19 power cord, 10 ft.
  • Configuration Cable
  • 24 x Plug-lock Inserts
  • Rack-mounting Hardware
  • Mounting Bracket Accessory
  • Owner's Manual
Mounting OrientationVertical
PlacementRack
Height70"
Width2.2"
Depth2.7"
Rack Height0U
Weight (Approximate)8.50 lb
Power Rating (Watt)3800 W
Input Voltage Range200 V AC - 240 V AC
Input Current20 A
Input Voltage230 V AC
Output Voltage230 V AC
Input ReceptaclesNEMA L6-20PIEC 60320 C20
Output Receptacles4 x IEC 60320 C1920 x IEC 60320 C13
ManagementProtocols:
  • HTTP
  • HTTPS
  • SMTP
  • SNMPv1
  • SNMPv2
  • SNMPv3
  • telnet
  • SSH
  • FTP
  • DHCP
  • NTP
Limited Warranty2 Year
The PDUMV20HVNETLX 3.2-3.8kW Single-Phase Switched PDU provides advanced network control and remote power monitoring with the ability to turn on, turn off, reboot or lock out power to each outlet. Recommended for any IT or industrial application, it features 24 switched outlets (20 C13 and 4 C19) with included plug-lock insert sleeves to prevent cables from becoming accidentally disconnected. A 10-foot cord with NEMA L6-20P plug connects the PDU's C20 inlet to a compatible AC power source, generator or protected UPS.The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP. A digital ammeter allows you to monitor each bank's load in real time to ensure it remains well below maximum capacity with no danger of overload. The vertical PDU mounts in 0U of space in EIA-standard 19-inch racks using the included toolless mounting buttons or the included rack-mounting brackets. Use the included PDUMVROTATEBRKT kit to install the unit with outlets facing the rear for better airflow or equipment access.
