Tripp Lite PDUMV15NETLX 16-Outlet PDU
Manufacturer: Tripp Lite
UPC: 037332205193
SKU: PDUMV15NETLX
Condition: New
Tripp Lite PDUMV15NETLX 16-Outlet PDU
Price $727.96
Product TypePDU
Brand NameTripp Lite
ManufacturerTripp Lite
Product ModelPDUMV15NETLX
Product NamePDUMV15NETLX 16-Outlet PDU
Manufacturer Part NumberPDUMV15NETLX
Manufacturer Website Addresshttp://www.tripplite.com
Environmentally FriendlyYes
Environmental CertificationRoHS
TAA CompliantYes
Package Contents
  • PDUMV15NETLX 16-Outlet PDU
  • Built-in LX Platform Interface
  • Configuration Cable
  • 16 x Cable Ties
  • 2 x Cord Retention Brackets
  • Rack-mounting Hardware
  • PDUMVROTATEBRKT Mounting Bracket Accessory
  • Owner's Manual
Mounting OrientationVertical
PlacementRack
Height49"
Width2.2"
Depth2.7"
Rack Height0U
Weight (Approximate)7 lb
Power Rating (Watt)1520 W
Input Current15 A
Input Voltage120 V AC
Output Voltage100 V AC120 V AC127 V AC
Input ReceptaclesNEMA 5-15P
Output Receptacles16 x NEMA 5-15R
ManagementProtocols:
  • IPv4
  • IPv6
  • HTTP
  • HTTPS
  • SMTP
  • SNMPv1
  • SNMPv2
  • SNMPv3
  • telnet
  • SSH
  • FTP
  • DHCP
  • NTP
Limited Warranty2 Year
The PDUMV15NETLX 1.4kW Single-Phase Switched PDU provides advanced network control and remote power monitoring with the ability to turn on, turn off, reboot or lock out power to each outlet. Recommended for IT and industrial applications, the vertical PDU features 16 switched NEMA 5-15R outlets with included cord retention brackets to prevent cables from becoming accidentally disconnected. A 10-foot cord with NEMA 5-15P plug connects the PDU to a compatible AC power source, generator or protected UPS. The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP. A digital ammeter allows you to monitor the total load in real time to ensure it remains well below maximum capacity with no danger of overload. The vertical PDU mounts in 0U of space in EIA-standard 19-inch racks using the included toolless mounting buttons or the included rack-mounting brackets. Use the included PDUMVROTATEBRKT kit to install the unit with outlets facing the rear for better airflow or equipment access.
