Tripp Lite PDUMNV32HV2LX 42-Outlet PDU
Manufacturer: Tripp Lite
UPC: 037332204899
SKU: PDUMNV32HV2LX
Condition: New
Tripp Lite PDUMNV32HV2LX 42-Outlet PDU
Price $705.87
Product TypePDU
Brand NameTripp Lite
ManufacturerTripp Lite
Product ModelPDUMNV32HV2LX
Product NamePDUMNV32HV2LX 42-Outlet PDU
Manufacturer Part NumberPDUMNV32HV2LX
Manufacturer Website Addresshttp://www.tripplite.com
Environmentally FriendlyYes
Environmental CertificationRoHS
TAA CompliantYes
Package Contents
  • PDUMNV32HV2LX 42-Outlet PDU
  • Built-in LX Platform Interface
  • Configuration Cable
  • 42 x Plug-lock Insert Sleeves
  • Rack-mounting Hardware
  • Mounting Bracket Accessory
  • Owner's Manual
Mounting OrientationVertical
PlacementRack
Height70"
Width2.2"
Depth2.7"
Rack Height0U
Form FactorRack-mountable
Weight (Approximate)9.70 lb
Power Rating (Watt)7700 W
Input Current32 A
Input Voltage230 V AC
Output Voltage200 V AC208 V AC220 V AC230 V AC240 V AC
Input ReceptaclesIEC 60309 32A BLUE (2P+E)
Output Receptacles6 x IEC 60320 C1936 x IEC 60320 C13
Protection TypeOverload Protection
ManagementProtocols:
  • IPv4
  • IPv6
  • HTTP
  • HTTPS
  • SMTP
  • SNMPv1
  • SNMPv2
  • SNMPv3
  • telnet
  • SSH
  • FTP
  • DHCP
  • NTP
Limited Warranty2 Year
The PDUMNV32HV2LX 7.4kW Single-Phase Monitored PDU provides real-time remote monitoring of voltage, frequency and load levels via built-in network connection. By reducing the frequency of on-site visits, these advanced remote capabilities can save you money and reduce downtime.The 0U PDU features 42 outlets (36 C13 and 6 C19) with included plug-lock insert sleeves to prevent cables from becoming accidentally disconnected. A 10-foot cord with IEC 309 32A Blue (2P+E) plug connects the PDU to a compatible AC power source, generator or protected UPS.The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP.A digital ammeter allows you to monitor each load bank's current and the total connected PDU load in real time to ensure they remain well below maximum capacity with no danger of overload. The PDU mounts in 0U of space in EIA-standard 19-inch racks using the included toolless mounting buttons or the included rack-mounting brackets. Use the included PDUMVROTATEBRKT kit to install the unit with outlets facing the rear for better airflow or equipment access.
