Tripp Lite N282-02M-28-BK QSFP28 to QSFP28 100GbE Passive DAC Copper InfiniBand Cable (M/M), 2 m (6
Manufacturer: Tripp Lite
UPC: 037332193155
SKU: N282-02M-28-BK
Condition: New
Tripp Lite N282-02M-28-BK QSFP28 to QSFP28 100GbE Passive DAC Copper InfiniBand Cable (M/M), 2 m (6
Product TypeNetwork Cable
Brand NameTripp Lite
ManufacturerTripp Lite
Product ModelN282-02M-28-BK
Product NameQSFP28 to QSFP28 100GbE Passive DAC Copper InfiniBand Cable (M/M), 2 m (6 ft)
Manufacturer Part NumberN282-02M-28-BK
Manufacturer Website Addresshttp://www.tripplite.com
Green CompliantYes
Green Compliance Certificate/AuthorityREACHRoHS
ColorBlack
Connector on First End1 x QSFP+ Male Network
Connector on Second End1 x QSFP+ Male Network
Cable TypeInfiniBand
American Wire Gauge26 AWG
FeaturesFlexibleCrosstalk ProtectionPassive
Data Transfer Rate12.50 GB/s
Device SupportedNetwork Device
Cable Length6.56 ft
Limited WarrantyLifetime
The N282-02M-28-BK QSFP28 to QSFP28 100GbE Passive DAC Copper InfiniBand Cable provides next-generation performance by combining four 28 Gbps SFP channels into one high-density cable. It's ideal for connecting active network equipment in data centers, high-end servers and enterprise wiring closets. This two-meter copper cable integrates a 100G Ethernet-optimized (100 GbE) 38-position "board-as-connector" design with zinc die-cast male QSFP+ connectors for superior EMI resistance, minimal insertion loss and low crosstalk for better performance. Ergonomic pull-tab ejectors make connecting to equipment a quick, easy task. Eight-pair wire technology is optimized for bandwidth-intense applications, including 100-Gigabit Ethernet (100GBASE-CR4), 128G Fibre Channel and EDR 4x InfiniBand.Flexible 26 AWG conductors maintain a smooth high-frequency response. The N282-02M-28-BK undergoes a rigorous assembly and testing procedure aimed at eliminating unnecessary signal loss. It's fully compliant with the MSA (Multi-Source Agreement) SFF-8665 architecture for guaranteed compatibility with all QSFP and QSFP+ ports, as well as RoHS and IEEE 802.3bj.
