Tripp Lite B155-002-DP-V2 2-Port Mini DisplayPort 1.2 to DisplayPort MST Hub
Manufacturer: Tripp Lite
UPC: 037332193421
SKU: B155-002-DP-V2
Condition: New
Tripp Lite B155-002-DP-V2 2-Port Mini DisplayPort 1.2 to DisplayPort MST Hub
Product TypeSignal Splitter
Brand NameTripp Lite
ManufacturerTripp Lite
Product ModelB155-002-DP-V2
Product NameB155-002-DP-V2 2-Port Mini DisplayPort 1.2 to DisplayPort MST Hub
Manufacturer Part NumberB155-002-DP-V2
Manufacturer Website Addresshttp://www.tripplite.com
Maximum Frequency30 Hz
Minimum Frequency24 Hz
Environmentally FriendlyYes
Environmental CertificationRoHSREACH
TAA CompliantYes
Package Contents
  • B155-002-DP-V2 2-Port Mini DisplayPort 1.2 to DisplayPort MST Hub
  • USB Micro-B Cable, 3 ft.
  • Owner's Manual
Maximum Video Resolution3840 2160
DisplayPortYes
Number of DisplayPort Outputs2
Number of DisplayPort Inputs1
Height1"
Width3"
Depth2.4"
Weight (Approximate)3.20 oz
Limited Warranty1 Year
The B155-002-DP-V2 2-Port Mini DisplayPort 1.2 to DisplayPort MST Hub connects two DisplayPort monitors to the Mini DisplayPort output on your computer. Ideal for digital signage in schools, churches, conference rooms, trade shows, hotels and retail outlets, this hub allows you to display the same image on both monitors, extend the desktop across them, or combine both into one large monitor in video wall mode.The B155-002-DP-V2 is compliant with DisplayPort 1.2 and backward compatible with versions 1.1 and 1.1a with the feature set being limited to that of your equipment. It supports Ultra High Definition (UHD) video resolutions up to 3840 x 2160 (4K x 2K) at 24/30 Hz. This MST hub also supports HDCP, EDID, DDC and 48-bit Deep Color (16 bits per channel), as well as DTS-HD, Dolby TrueHD and 7.1-channel surround sound audio. The B155-002-DP-V2 works with all operating systems. Plug-and-play convenience means no software, drivers or external power supply is needed. The included three-foot USB Micro-B cable delivers necessary power from the connected computer. A built-in six-inch cable connects directly to a Mini DisplayPort source. LEDs indicate when the monitors are receiving a signal. The B155-002-DP-V2 complies with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.
