Tripp Lite B132-004-2 VGA over Cat5 Extender 4-Port Transmitter
Manufacturer: Tripp Lite
UPC: 037332178442
SKU: B132-004-2
Condition: New
Tripp Lite B132-004-2 VGA over Cat5 Extender 4-Port Transmitter
Price $140.56
Product TypeVideo Extender
Brand NameTripp Lite
ManufacturerTripp Lite
Product ModelB132-004-2
Product NameVGA over Cat5 Extender 4-Port Transmitter
Manufacturer Part NumberB132-004-2
Manufacturer Website Addresshttp://www.tripplite.com
Green CompliantYes
Green Compliance Certificate/AuthorityRoHS
Package Contents
  • VGA over Cat5 Extender 4-Port Transmitter
  • 1 ft. VGA daisychain cable
  • Mounting hardware
  • External Power Supply (Input: 100-240V, 50/60Hz, 1.5A Output: 12.6V, 3A)
  • Owner's Manual
Maximum Video Resolution1920 x 1440
Twisted Pair Cable StandardCategory 6
Media Type SupportedTwisted Pair
Maximum Operating Distance1000 ft
Number of Output Devices Supported5
Number of Input Devices Supported1
Connectivity TechnologyWired
Number of Network (RJ-45) Ports4
Number of VGA Outputs1
VGA InYes
VGA OutYes
Number of VGA Inputs1
Height1.2"
Width5.3"
Depth3.9"
ColorBlack
Form FactorRack-mountableWall MountablePole-mountable
Weight (Approximate)13.60 oz
Limited Warranty1 Year
Tripp Lite's B132-004-2 allows you to split a single VGA signal into 5 (1 local, 4 remote). Increase the number of displays to up to 25 (1 local, 24 remote) by daisy-chaining up to six B132-004-2 units together. Along with a B132-100-1 or B132-100-WP-1 remote receiver unit, you can extend a 1920 x 1440 (60Hz) signal up to 500 ft., or a 1024 x 768 (60Hz) signal up to 1,000 ft., when using 24Awg, Solid Wire Cat5e/6 cable, such as Tripp Lite's N022-01K-GY (Cat5) and N222-01K-GY (Cat6). The range and number of monitors can be further expanded by adding B132-110 repeater units. Connect up to 4 remote units in a repeater chain (3 repeaters and 1 receiver), with a monitor at each location. A 1920 x 1440 (60Hz) signal can be extended up to 500 ft. from the first repeater in the chain to the last receiver. A 1024 x 768 (60Hz) signal can be extended up to 1,000 ft. from the first repeater in the chain to the last receiver. For optimal video image quality between 500 and 1,000 ft., use Zero-Skew cable, such as Tripp Lite P524-01K. The transmitter unit features functionality that allows for the EDID information from a connected display to be copied and sent to the connected computer, providing optimal compatibility. Includes mounting hardware that allows unit to be wallmounted, rackmounted or pole mounted. Up to three B132-004-2 units can be mounted in 1U of rack space using a Tripp Lite B132-004-RB Extender/Splitter 19 in. rackmount bracket. Ideal for digital signage situations, such as retail, schools, churches, etc. Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.
