Tripp Lite B126-002 Video Extender
Manufacturer: Tripp Lite
UPC: 037332157508
SKU: B126-002
Condition: New
Tripp Lite B126-002 Video Extender
Product TypeVideo Extender
Brand NameTripp Lite
ManufacturerTripp Lite
Product ModelB126-002
Product NameB126-002 Video Extender
Manufacturer Part NumberB126-002
Manufacturer Website Addresshttp://www.tripplite.com
Green CompliantYes
Green Compliance Certificate/AuthorityRoHS
Package Contents
  • B126-002 Video Extender
  • Mounting Hardware
  • External Power Supply
  • Owner's Manual
Twisted Pair Cable StandardCategory 6
Media Type SupportedTwisted Pair
Maximum Operating Distance200 ft
Number of Output Devices Supported2
Number of Input Devices Supported1
Connectivity TechnologyWired
Number of Network (RJ-45) Ports2
Network (RJ-45)Yes
Number of HDMI Inputs1
HDMI InYes
Height1"
Width2.5"
Depth3.6"
ColorBlack
Limited Warranty1 Year
The B126-002 transmits a 1080p (60Hz) signal to two monitors up to 150 ft. away using Cat5e/6 cable. To achieve maximum distance and resolution, use 24Awg Solid Wire Cat5e/6 cable. (Tripp Lite's N202-Series) Supports 24-bit True Color (8-bits per channel), HDCP, 3D, and both stereo audio and 7.1 channel surround sound audio (7.1 channel surround sound signal will be Multi-Channel or PCM). Installation is simple. Connect the B126-002 transmitter to an HDMI source using a Tripp Lite P568-Series HDMI cable (not included). Connect a Tripp Lite B126-series receiver (not included) to each display using a Tripp Lite P568-Series HDMI cable (not included). Finally, each remote receiver is connected to an RJ45 port on the B126-002 using a single Cat5e/6 cable. Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.
