Tripp Lite B119-005-UHD 5-Port HDMI Switch with Remote - 4K x 2K UHD @ 60 Hz
Manufacturer: Tripp Lite
UPC: 037332210180
SKU: B119-005-UHD
Condition: New
Tripp Lite B119-005-UHD 5-Port HDMI Switch with Remote - 4K x 2K UHD @ 60 Hz
Product TypeAudio/Video Switchbox
Brand NameTripp Lite
ManufacturerTripp Lite
Product NameB119-005-UHD 5-Port HDMI Switch with Remote - 4K x 2K UHD @ 60 Hz
Manufacturer Part NumberB119-005-UHD
Manufacturer Website Addresshttp://www.tripplite.com
Graphics Modes4K
Maximum Video Resolution3840 2160
Environmentally FriendlyYes
Environmental CertificationRoHSREACH
Package Contents
  • B119-005-UHD 5-Port HDMI Switch with Remote - 4K x 2K UHD @ 60 Hz
  • Remote Control
  • External Power Supply (Input: 100-240V, 50/60 Hz, 0.3A; Output: 5V 1A)
  • 4 x International Plug adapters (North America, Europe, United Kingdom, Australia)
  • Owner's Manual
Number of HDMI Inputs5
Number of HDMI Outputs1
HDMI InYes
HDMI OutYes
Number of Displays Supported1
Number of Input Devices Supported5
Connectivity TechnologyCable
Device SupportedDisplayHome Theater SystemProjector
Height0.8"
Width4.8"
Depth2"
Weight (Approximate)5.29 oz
Limited Warranty3 Year
5-Port HDMI Switch with Remote Connects 5 Sources to One 4K HDMI Display An excellent addition to your home theater, the B119-005-UHD allows you to connect five separate HDMI audio/video sources to your 4K television, projector or monitor's HDMI input and switch between them. For instance, connect a cable box, Blu-ray player, Xbox, Roku and audio receiver to your 4K HDTV, and use the included remote control to switch manually from one input to another. Transmits Crystal-Clear Video up to 4K x 2K for Ultra High Definition Presentations This 5-port HDMI switch with remote ensures UHD performance with video resolutions up to 3840 x 2160 (4K x 2K) @ 60 Hz and 48-bit True Color (16 bits per channel), as well as DTS-HD, Dolby TrueHD and 7.1-channel surround sound audio. It meets 3D, HDMI 2.0, HDCP 2.2 and EDID standards. Switch between source devices using the unit's Select button or the remote control. Ready to Use Right from the Package, So You Can Plug and Play Immediately The compact metal switch requires no software or drivers to download and install. Connect your devices to the HDMI ports with user-supplied HDMI cables (such as Tripp Lite's P569-Series), and plug the included external power supply into an AC power source. A red LED indicates the unit is receiving power, and green LEDs indicate connected HDMI inputs. When the currently used source is powered off, the unit automatically switches to the next powered-on source. 3-Year Warranty The B119-005-UHD is backed by a 3-year warranty, ensuring reliability and performance.
