Tripp Lite B110-SP-HDMI Surge Suppressor/Protector
Manufacturer: Tripp Lite
UPC: 037332217868
SKU: B110-SP-HDMI
Condition: New
Tripp Lite B110-SP-HDMI Surge Suppressor/Protector
Price $23.24
Product TypeSurge Suppressor/Protector
Brand NameTripp Lite
ManufacturerTripp Lite
Product ModelB110-SP-HDMI
Product NameB110-SP-HDMI Surge Suppressor/Protector
Manufacturer Part NumberB110-SP-HDMI
Manufacturer Website Addresshttp://www.tripplite.com
Environmentally FriendlyYes
Environmental CertificationRoHSREACH
TAA CompliantYes
Package Contents
  • B110-SP-HDMI Surge Suppressor/Protector
  • Grounding Wire, 1 ft.
  • 2 x Mounting Screws
  • 2 x Screw Anchors
  • Grounding Wire Screw
  • Quick Start Guide
Power Cord/Cable Length1 ft
Height1"
Width2.3"
Depth1"
Weight (Approximate)1.41 oz
Receptacles1 x HDMI
Input Voltage120 V AC230 V AC
Limited Warranty2 Year
In-Line Surge Protector Keeps Your HDMI Source or Display Safe Ideal for trade shows, convention halls, home theaters and other digital signage applications, the B110-SP-HDMI protects connected equipment from damage caused by lightning, electrostatic discharge (ESD) and cable discharge events. Just connect it between your source and display using HDMI cables, such as Tripp Lite's P568-003-Series high-speed cables (sold separately). Note: two B110-SP-HDMI surge protectors are required to protect both source and display. Your Last Defense Against Intruding Voltage Spikes Solid-state silicon-avalanche diode technology features low clamping voltage, providing superior protection against ESD and super-fast response time under one nanosecond. Low TDMS (Transition Minimized Differential Signaling) loss ensures you get the crispest and cleanest image on your display without any interference, including static lines. The B110-SP-HDMI meets the following IEC regulations: IEC 61000-4-2 (ESD) +/- 15kV (air), +/- 8kV (contact); IEC 61000-4-4 (EFT) 40A (5/50ns); and IEC 61000-4-5 (Lightning) 5A (8/20µs). Ready to Use Right from the Package, So You Can Plug and Play Immediately This HDMI in-line surge protector supports 4K x 2K resolutions up to 3840 x 2160 at 30 Hz, as well as HDMI 1.4 and HDCP 2.2 specifications. It is a passive design and requires no external power supply. The compact metal housing is designed to endure in applications where static discharge is likely to occur. Mounting hardware is included for convenient installation where needed. Be sure the distance between the B110-SP-HDMI and the equipment it is protecting is no more than 3 feet. TAA-Compliant for GSA Schedule Purchases The B110-SP-HDMI is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.
