Transition Networks SI-IES-1200-LRT Hardened 1-port Mid-span PoE+ Injector
Manufacturer: Transition Networks
UPC: 648177038220
SKU: SI-IES-1200-LRT
Condition: New
Transition Networks SI-IES-1200-LRT Hardened 1-port Mid-span PoE+ Injector
Specifications
Input Ports1 10/100/1000Base-T
Output Ports1 10/100/1000Base-T
Product TypePoE Injector
Brand NameTransition Networks
ManufacturerTransition Networks, Inc
Product ModelSI-IES-1200-LRT
Product NameHardened 1-port Mid-span PoE+ Injector
Manufacturer Part NumberSI-IES-1200-LRT
Manufacturer Website Addresshttp://www.transition.com
Green CompliantYes
Green Compliance Certificate/AuthorityWEEERoHS
Certifications & Standards
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3ab
  • IEEE 802.3at
  • UL508
  • IP30
  • FCC Class A
  • CE Mark
  • EN61000-6-4
  • EN61000-6-2; EN61000-4-2 (ESD)
  • EN61000-4-3 (RS)
  • EN61000- 4-4 (EFT)
  • EN61000-4-5 (Surge)
  • EN61000-4-6(CS) EN61000-4-8 (Magnetic Field)
  • IEC60068-2-27 (Shock)
  • IEC60068-2-32 (Free fall)
  • IEC60068-2-6 (Vibration)
Compatibility
  • Wireless Access Point
  • Camera
Height5.5"
Width1.2"
Depth3.7"
Form FactorExternal
Mount TypeDIN Rail/Wall Mountable
Maximum Output Power30 W
Input Voltage24 V DC48 V DC
Limited WarrantyLifetime
Description
The SI-IES-1200-LRT is a industrial grade 1-port 10/100/1000Base-T PoE+ Mid-span Injector which provides a simple solution to enabling the existing infrastructure with IEEE802.3at PoE+ capability. Transition Networks' Industrial Mid-span Injectors are designed to reliably operate in harsh environments such as those found on factory floors, out-door enclosures or other hazardous environments.
