Supermicro MBD-X11DAI-N-O Workstation Motherboard
Manufacturer: Supermicro
UPC: 672042279630
Condition: New
Supermicro MBD-X11DAI-N-O Workstation Motherboard
Product TypeWorkstation Motherboard
Brand NameSupermicro
ManufacturerSupermicro Computer, Inc
Product ModelX11DAi-N
Product NameX11DAi-N Workstation Motherboard
Package TypeRetail
Manufacturer Part NumberMBD-X11DAI-N-O
Manufacturer Website Addresshttp://www.supermicro.com
Packaged Quantity1
Chipset ManufacturerIntel
Processor SocketSocket P LGA-3647
Processor SupportedXeon
Total Processor Supported2
Number of Memory Slots16
Memory Speed Supported2.67 GHz2.40 GHz2.13 GHz
Memory TechnologyDDR4 SDRAM
Maximum Memory2 TB
Graphics Controller ManufacturerASPEED
Graphics Controller ModelAST2500
Onboard VideoOn-board Video Chipset
Audio Channels7.1
Gigabit EthernetYes
Number of SATA Interfaces10
Total Number of Onboard USB Ports4
Number of Onboard USB 3.0 Ports4
Number of M.2 Interfaces1
Number of NVMe Ports2
RAID SupportedYes
RAID Levels10510
Controller TypeSerial ATA/600
Number of Total Expansion Slots6
Number of PCI Express x8 Slots2
Number of PCI Express x16 Slots4
Total Number of PCI Express Slots6
Total Number of USB Ports2
Number of USB 3.1 Ports2
Form FactorExtended ATX


  • SYS-7039A-I
  • SYS-7049A-T


  • SC732D4-903B
  • SC732D3-1200B
  • SC743AC-1200B-SQ
DP Xeon® Motherboards - Socket P (LGA 3647) BOARDS supporting Intel® Xeon® Scalable Processors / Socket P (LGA 3647)Supermicro's new generation X11 DP serverboards offer the highest levels of performance, efficiency, security and scalability in the industry with up to: 3TB DDR4 2666MHz in 24 DIMM slots per node, 7 PCI-E slots, SAS 3.0/SATA 3.0/NVMe hot-swap HDD/SSD support, 10GBase-T/10G SFP+/56Gbps FDR InfiniBand networking options, SATA Disk-on-Module (DOM), and IPMI 2.0 plus KVM with dedicated LAN. The SuperWorkstation boards offer in addition 7.1 HD Audio, Thunderbolt AOC header, and up to 11 USB ports.
