Supermicro MBD-X10SRL-F-B Server Motherboard
Manufacturer: Supermicro
UPC: 803929458941
SKU: MBD-X10SRL-F-B
Condition: New
Supermicro MBD-X10SRL-F-B Server Motherboard
Price $418.79
Out of Stock
Product Type Server Motherboard
Brand Name Supermicro
Manufacturer Supermicro Computer, Inc
Product Model X10SRi-F
Product Name X10SRi-F Server Motherboard
Package Type Bulk
Manufacturer Part Number MBD-X10SRL-F-B
Manufacturer Website Address http://www.supermicro.com
Packaged Quantity 1
Chipset Manufacturer Intel
Processor Socket Socket LGA 2011-v3
Processor Supported Xeon
Total Processor Supported 1
Number of Memory Slots 8
Memory Form Factor DIMM RDIMM LRDIMM
Memory Speed Supported 2.13 GHz 1.87 GHz 1.60 GHz
Memory Standard DDR4-2133/PC4-17000 DDR4-1866/PC4-14900 DDR4-1600/PC4-12800
Memory Technology DDR4 SDRAM
Maximum Memory 512 GB
Graphics Controller Manufacturer ASPEED
Graphics Controller Model AST2400
Onboard Video On-board Video Chipset
Gigabit Ethernet Yes
Number of SATA Interfaces 10
Total Number of Onboard USB Ports 8
Number of Onboard USB 3.0 Ports 2
RAID Supported Yes
RAID Levels 0 1 5
Controller Type Serial ATA/600
Number of Total Expansion Slots 6
Number of PCI Express x8 Slots 5
Number of PCI Express x16 Slots 1
Total Number of PCI Express Slots 6
VGA Yes
Total Number of USB Ports 4
Number of USB 3.0 Ports 2
Width 12"
Depth 9.6"
Form Factor ATX
Xeon® E5 Family BOARDS / Socket R3 (LGA 2011) Introducing Supermicro's latest generation of dual processor motherboard technology based on Intel's E5-2600 v3 Haswell processor. Supermicro's X10 motherboards are specifically designed to meet the demanding needs of today's complex computational workloads. Feature rich and highly expandable, our X10 motherboards provide the latest advanced integrated and expandable storage and networking technologies. Features like lightning fast DDR4 memory, NVMe/SAS3/SATA3 storage interfaces, 1G/10GBASE-T, 10G SFP+, 40GbE, and Infiniband QDR/FDR. With its unprecedented set of features, each X10 motherboard is specifically tailored to provide optimal performance while helping to reduce deployment and operational costs over the lifespan of the product.
