Supermicro SYS-6018R-MD SuperServer (Silver) 6018R-MD

Home > Computers / System > Barebone Computers

Manufacturer: Supermicro

Mfg Number: 6018R-MD

UPC: 0672042181056

SKU: SYS-6018R-MD

Condition: New

Supermicro SYS-6018R-MD SuperServer (Silver) 6018R-MD

Specifications

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	6018R-MD
Product Name	SuperServer 6018R-MD (Silver)
Product Line	SuperServer
Manufacturer Part Number	SYS-6018R-MD
Manufacturer Website Address	http://www.supermicro.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	SuperServer 6018R-MD (Silver) 1 x Super X10DRD-L Motherboard 1 x 1U Chassis 1 x Y split , big 4 pin to two RA SATA power extension 15cm, 18AWG 2 x 81CM 30AWG SATA S-S cable 1 x Optional shorter 1U riser card bracekt for X9DRL-7F/EF 1 x 3.5in fixed HDD tray for SC513,514,515,812L,812U,523,HF,RoHS/REACH 1 x Dual 2.5" fixed HDD bracket for SC514,515,HF,RoHS/REACH 1 x SYS-6018R-MD, QRG,HF,RoHS/REACH 1 x RSC-RR1U-E8 (Rev 4.00) 2 x 1U Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB 1 x 1U 500W Multi-output, Platinum level w/ PMbus 24pin, W100xL180xH40mm,RoHS/REACH 5 x 40x40x56 mm 13K-11K RPM Counter-rotating Fan
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C612
Number of Processors Supported	2
Processor Socket	Socket LGA 2011-v3
Processor Supported	Xeon
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Number of SATA Interfaces	6
Total Number of USB Ports	7
Number of Power Supplies Installed	1
Maximum Power Supply Wattage	500 W
Input Voltage	120 V AC230 V AC
Number of Total Memory Slots	8
Memory Standard	DDR4-2133/PC4-17000
Memory Technology	DDR4 SDRAM
Maximum Memory	512 GB
RAID Supported	Yes
Controller Type	Serial ATA/600
Ethernet Technology	Gigabit Ethernet
Number of Total Expansion Slots	1
Number of PCI Express x8 Slots	1
Height	1.7"
Width	17.2"
Depth	16.9"
Color	Silver
Rack Height	1U
Form Factor	Rack-mountable
Limited Warranty	3 Year

Description

Supermicro's New Generation X10 Haswell DP SuperServer® offers numerous advantages over previous generations including the highest levels of performance, efficiency, security and scalability in the industry.
