Supermicro MBD-X11SSQ-O Server Motherboard X11SSQ
Manufacturer: Supermicro
Mfg Number: X11SSQ
UPC: 672042195688
Condition: New
Supermicro MBD-X11SSQ-O Server Motherboard X11SSQ
Product TypeServer Motherboard
Brand NameSupermicro
ManufacturerSupermicro Computer, Inc
Product ModelX11SSQ
Product NameX11SSQ Server Motherboard
Package TypeOEM
Manufacturer Part NumberMBD-X11SSQ-O
Manufacturer Website Addresshttp://www.supermicro.com
Chipset ManufacturerIntel
Chipset ModelQ170
Processor SocketSocket H4 LGA-1151
Processor SupportedCore i7Core i5Core i3PentiumCeleron
Total Processor Supported1
Number of Memory Slots4
Memory Form FactorDIMMUDIMM
Memory Speed Supported2.13 GHz1.87 GHz1.60 GHz
Memory TechnologyDDR4 SDRAM
Maximum Memory64 GB
Audio Channels7.1
Gigabit EthernetYes
Number of SATA Interfaces6
Total Number of Onboard USB Ports6
Number of Onboard USB 3.0 Ports2
Number of PCI Express x1 Slots1
Number of Total Expansion Slots4
Number of PCI Express x4 Slots2
Number of PCI Express x16 Slots1
Total Number of PCI Express Slots4
RAID SupportedYes
RAID Levels01510
Controller TypeSerial ATA/600
Total Number of USB Ports6
Number of USB 3.0 Ports2
Form FactorMicro ATX
CompatibilitySupermicro SuperChassis

2U Chassis:
  • SC825MTQ-R700LPB
  • SC823MTQ-R700LPB
Mid/Mini Tower Chassis:
  • SC731i-300B
4U / Tower Chassis:
  • SC842i-500B
6th Generation Core™ Processor Based MotherboardsQ170 chipset / Socket H4 Boards Supermicro's single processor Socket H4 designs feature the Intel® Q170 embedded chipset which support the Intel® 6th Gen Core i3/i5/i7 processor family. With outstanding features that include up to 64GB of fast DDR4 DRAM in 4 DIMMS, onboard IPMI or vPro, USB 3.0, PCI-E 3.0 and SATA 3.0 (6Gbps) HDD. With support for next generation graphics controller, 4K HD graphics resolution and 3 displays with HDMI, DP, VGA and DVI ports. Designed with performance, reliability, manageability and long life in mind Supermicro's single processor motherboards are the perfect solution for ATM, Kiosk, NVR/DVR Surveillance, Medical, Storage or Server appliance and many other embedded applications.
