Supermicro MBD-X10SRL-F-O Server Motherboard X10SRL-F
Manufacturer: Supermicro
Mfg Number: X10SRL-F
UPC: 0672042156115
Condition: New
Supermicro MBD-X10SRL-F-O Server Motherboard X10SRL-F
Product TypeServer Motherboard
Brand NameSupermicro
ManufacturerSupermicro Computer, Inc
Product ModelX10SRL-F
Product NameX10SRL-F Server Motherboard
Package TypeRetail
Manufacturer Part NumberMBD-X10SRL-F-O
Manufacturer Website Addresshttp://www.supermicro.com
Green CompliantYes
Green Compliance Certificate/AuthorityRoHS
CompatibilitySupermicro SuperChassis

1U Chassis:
  • CSE-813MFTQ-441CB
  • CSE-813MFTQ-R400CB
2U Chassis:
  • CSE-823TQ-653LPB
  • CSE-825TQ-R600LPB
  • CSE-732D4F-903B
  • CSE-732i-500B
Tower / 4U Rackmount:
  • CSE-743T-665B
  • CSE-842i-500B
  • CSE-842TQ-665B
  • CSE-842TQ-865B
Chipset ManufacturerIntel
Chipset ModelC612
Processor SocketSocket R3 (LGA2011-3)
Processor SupportedXeon
Total Processor Supported1
Number of Memory Slots8
Memory Speed Supported2.13 GHz1.87 GHz1.60 GHz
Memory TechnologyDDR4 SDRAM
Maximum Memory512 GB
Graphics Controller ManufacturerASPEED
Graphics Controller ModelAST2400
Onboard VideoOn-board Video Chipset
Gigabit EthernetYes
Number of SATA Interfaces10
Total Number of Onboard USB Ports8
Number of Onboard USB 3.0 Ports2
Number of Total Expansion Slots7
Number of PCI Express x8 Slots5
Number of PCI Express x16 Slots2
Total Number of PCI Express Slots7
Total Number of USB Ports4
Number of USB 3.0 Ports2
Form FactorATX
Controller TypeSerial ATA/600
Xeon® E5 Family BOARDS / Socket R3 (LGA 2011) Introducing Supermicro's latest generation of dual processor motherboard technology based on Intel's E5-2600 v3 Haswell processor. Supermicro's X10 motherboards are specifically designed to meet the demanding needs of today's complex computational workloads. Feature rich and highly expandable, our X10 motherboards provide the latest advanced integrated and expandable storage and networking technologies. Features like lightning fast DDR4 memory, NVMe/SAS3/SATA3 storage interfaces, 1G/10GBASE-T, 10G SFP+, 40GbE, and Infiniband QDR/FDR. With its unprecedented set of features, each X10 motherboard is specifically tailored to provide optimal performance while helping to reduce deployment and operational costs over the lifespan of the product.
