StarTech.com ST121USBHD HDMI over CAT6 Extender with 4-port USB Hub - 165 ft (50m) - 1080p
Manufacturer: StarTech.com
UPC: 065030862363
SKU: ST121USBHD
Condition: New
StarTech.com ST121USBHD HDMI over CAT6 Extender with 4-port USB Hub - 165 ft (50m) - 1080p
Product TypeVideo Console/Extender
Brand NameStarTech.com
ManufacturerStarTech.com
Product NameHDMI over CAT6 Extender with 4-port USB Hub - 165 ft (50m) - 1080p
Manufacturer Part NumberST121USBHD
Manufacturer Website Addresshttp://www.startech.com
Graphics ModesWUXGA
Maximum Video Resolution1920 x 1200
Green CompliantYes
Green Compliance Certificate/AuthorityRoHSWEEE
Package Contents
  • 1 x HDMI over CAT6 Transmitter
  • 1 x HDMI over CAT6 Receiver
  • 2 x Ethernet Cables
  • 2 x USB to Mini-USB Cables
  • 1 X Universal Power Adapter (NA/EU/UK/AU)
  • 1 x Mounting Kit
  • 1 X Quick Install Guide
Twisted Pair Cable StandardCategory 6
Media Type SupportedTwisted Pair
Maximum Operating Distance260 ft
Number of Output Devices Supported1
Number of Input Devices Supported1
Connectivity TechnologyWired
USBYes
Number of Network (RJ-45) Ports4
Network (RJ-45)Yes
Number of USB Ports5
Serial PortYes
Number of HDMI Inputs1
Number of HDMI Outputs1
HDMI InYes
HDMI OutYes
Limited Warranty2 Year
Extend 1080p video and four USB peripheral devices to a remote location. This HDMI® extender kit lets you transmit your 1080p HD video source to your remote HDMI display at distance of up to 165 ft. away (50 m) using shielded CAT6 cabling. The extender features a built-in 4-port USB 2.0 hub that also lets you connect four remote USB peripheral devices at your display location.Crystal-clear picture qualityUsing this HDMI extender, you can maintain the quality of your high-definition video signal along with the accompanying 7.1 digital audio, even at 165 feet away from your source device. The extender supports resolutions up to 1920x1200 or 1080p - perfect for dazzling your audience in remote digital-signage applications in hospitals or at shopping centers.Hassle-free remote USB integrationThe built-in 4-port USB 2.0 hub lets you remotely connect, access or control up to four USB devices located at your remote display - great for flash drives, printers, scanners, external hard drives and I/O devices. Remote USB extension also enables you to remotely control your source device, which is ideal for adding touchscreen interfaces at your display in market or POS kiosks.Easy installation and setupFor hassle-free setup the HDMI extender offers easy plug-and-play installation with no additional software or drivers required. Plus, the extender passes the EDID information included in your HDMI signal, and automatically adjusts video equalization ensuring you won't have to configure it manually. Mounting hardware is also included, for a tidy and professional installation.Note: To maximize performance this extender requires shielded CAT6 cable. When using unshielded CAT6 cable the maximum distance is reduced to 30m. When using CAT5 cable the maximum distance is reduced to 15m. The ST121USBHD is backed by a 2-year StarTech.com warranty and free lifetime technical support.
