SmartAVI CSWX48X64S CAT5 Audio/Video and IR/RS232 48 IN X 64 OUT Matrix with RS-232 Control
Manufacturer: SmartAVI
UPC: 0813280020923
SKU: CSWX48X64S
Condition: New
SmartAVI CSWX48X64S CAT5 Audio/Video and IR/RS232 48 IN X 64 OUT Matrix with RS-232 Control
Product TypeAudio/Video Switchbox
Brand NameSmartAVI
ManufacturerSmart Audio Video Innovation
Product ModelCSWX48X64S
Product NameCAT5 Audio/Video and IR/RS232 48 IN X 64 OUT Matrix with RS-232 Control
Product LineCATXPro
Manufacturer Part NumberCSWX48X64S
Manufacturer Website Addresshttp://www.smartavi.com
Graphics ModesWUXGA
Maximum Video Resolution1920 x 1200
Maximum Operating Distance1000 ft
Media Type SupportedTwisted Pair
Number of Displays Supported64
Number of Input Devices Supported48
Connectivity TechnologyCable
Device SupportedDisplayComputerCameraTV
Connectivity (RJ-45)Yes
Number of Connectivity (RJ-45) Ports112
Country of OriginUnited States
Package Contents
  • CAT5 Audio/Video and IR/RS232 48 IN X 64 OUT Matrix with RS-232 Control
  • Software CD
  • CCPWR06US Cable
Height15.8"
Width17"
Depth14"
Form FactorRack-mountable
Weight (Approximate)20 lb
Limited Warranty1 Year
CATXPro routes audio, video, IR and RS/232 signals from several different video sources out to multiple displays (projectors, monitors, etc.) and speakers via inexpensive Cat5/6 UTP cable.CATXPro is capable of connecting to as many as 16 video sources via transmitters and 16 video displays via receivers with a maximum extension of 1,000 feet between the transmitter and receiver units.A single audio/video output can be routed to one or multiple destinations. Video is transmitted at a resolution of 1920 x 1200 to insure high resolution images. Buffered video outputs and analog delivery of stereo audio maintains optimum integrity throughout the system. Special remote boxes offer compatibility with Video Composite , UXGA, Component Video and S-Video.
