SIIG CE-H24N11-S1 HDMI 2.0 4K HDR 1x4 Splitter HDBaseT Extender with Auto-scaling
Manufacturer: SIIG
UPC: 818263304410
SKU: CE-H24N11-S1
Condition: New
SIIG CE-H24N11-S1 HDMI 2.0 4K HDR 1x4 Splitter HDBaseT Extender with Auto-scaling
Product TypeVideo Extender Transmitter/Receiver
Brand NameSIIG
ManufacturerSIIG, Inc
Product NameHDMI 2.0 4K HDR 1x4 Splitter HDBaseT Extender with Auto-scaling
Manufacturer Part NumberCE-H24N11-S1
Manufacturer Website Addresshttp://www.siig.com
Graphics Modes4K
Maximum Video Resolution3840 x 2160
Environmentally FriendlyYes
Environmental CertificationRoHSWEEE
TAA CompliantYes
Country of OriginTaiwan
Package Contents
  • 1 x Transmitter
  • 3 x Receivers
  • 1 x Power Adapter DC 12V / 7.5A
  • 1 x IR Blaster
  • 3 x IR Receiver
  • 4 x Terminal block
  • Mounting kit (Screw kit:4x20 mm 8pcs, Mounting ears 6pcs, Screw kit: 3x4 mm 12pcs)
  • 4 x Rubber Pad
  • User Manual
Twisted Pair Cable StandardCategory 6
Media Type SupportedTwisted Pair
Maximum Operating Distance198 ft
Number of Output Devices Supported2
Number of Input Devices Supported1
Connectivity TechnologyWired
USBYes
Number of Network (RJ-45) Ports6
Network (RJ-45)Yes
Number of USB Ports2
Number of HDMI Inputs1
Number of HDMI Outputs4
HDMI InYes
HDMI OutYes
Transmitter Height0.98"
Transmitter Width5.83"
Transmitter Depth12.80"
Receiver Height0.75"
Receiver Width2.76"
Receiver Depth5.47"
Transmitter Weight (Approximate)3.06 lb
Receiver Weight (Approximate)6.24 oz
Form FactorDesktop
Limited Warranty3 Year
Extends HDMI signals to four HDMI Receivers over CAT5e/6 cable up to 198ft with resolution auto-scaling, IR control, and Power over Cable support Extends Full HD 1080p HDMI signals up to 198ft (60m) and [email protected] signals up to 114ft (35m) over CAT5e/6 cable Supports [email protected] YUV 4:4:4 8-bit, [email protected] HDR YUV 4:2:0 10-bit Supports PoC (Power over Cable) technology which allows the transmitter and receiver unit(s) to be powered by only one power supply connected to the transmitter unit Transmitter unit supports two HDMI loop-outs for addition local display connections Receiver unit supports 2 HDMI outputs for more display connections Note: Additional Receiver (part# CE-H24P11-S1) sold separately. Supports EDID management for increased device compatibility Supports resolution auto-down scaling from 4K to 1080p allowing displays of different capabilities to be connected simultaneously Pure unaltered uncompressed 7.1ch digital HDMI over CAT5e/6 cable transmission offers the best audio signal DTS-HD Master Audio and Dolby TrueHD high bit rate audio for true sound compatibility Supports full bi-directional IR pass-through signal from 30KHz to 56KHz frequency
