SIIG CE-H23311-S1 4K HDR HDMI 2.0 HDBaseT Extender Over Single Cat5e/6 with RS-232 & IR - 100m
Manufacturer: SIIG
UPC: 662774041155
SKU: CE-H23311-S1
Condition: New
SIIG CE-H23311-S1 4K HDR HDMI 2.0 HDBaseT Extender Over Single Cat5e/6 with RS-232 & IR - 100m
Product TypeVideo Extender Transmitter/Receiver
Brand NameSIIG
ManufacturerSIIG, Inc
Product Name4K HDR HDMI 2.0 HDBaseT Extender Over Single Cat5e/6 with RS-232 & IR - 100m
Manufacturer Part NumberCE-H23311-S1
Manufacturer Website Addresshttp://www.siig.com
Graphics Modes4K
Maximum Video Resolution3840 x 2160
Environmentally FriendlyYes
Environmental CertificationRoHS
Country of OriginTaiwan
Package Contents
  • 1 x Transmitter (TX)
  • 1 x Receiver (RX)
  • Power Adapter
  • IR Blaster Extension Cable & IR Receiver Extension Cable
  • 4 x Mounting Ears & Screw kit (8+4)
  • User Reference Guide
Twisted Pair Cable StandardCategory 6
Media Type SupportedTwisted Pair
Maximum Operating Distance328.08 ft
Number of Output Devices Supported1
Number of Input Devices Supported1
Connectivity TechnologyWired
Number of Network (RJ-45) Ports2
Network (RJ-45)Yes
Serial PortYes
Number of HDMI Inputs1
Number of HDMI Outputs1
HDMI InYes
HDMI OutYes
Height0.8"
Width2.8"
Depth4.7"
Form FactorWall Mountable
Weight (Approximate)9.28 oz
Limited Warranty3 Year
Extends HDMI audio and video signals, RS232 control, IR control up to 100 meters over a single CAT5e/6 cable with industry recognized HDBaseT technology Extends HDMI 2.0 audio and video signal from your HDMI source to a remote HDMI display up to 330ft (100m) away at Full HD 1080p, or 230ft (70m) at 3840x2160@60Hz (4:4:4 8bit/HDR10 4:2:0 10bit) through a single premium quality CAT5e/6 cable Delivers crystal clear picture quality with resolution up to 3840x2160 @60Hz YUV444 8bit and HDR 3840x2160 @60Hz YUV420 10bit Pure unaltered uncompressed 7.1ch digital HDMI over CAT cable transmission, DTS-HD Master Audio and Dolby TrueHD high bit rate audio support Supports PoC (Power over Cable) technology which allows both the transmitter and receiver units to be powered through only one power adapter Bi-directional IR sensors allow you to remotely control the HDMI source device from the remote display side or control the remote display from the source device side High quality metal housing with cooling slots provide excellent ESD and electromagnetic protection plus excellent heat dissipation and cooling for stable operation during extended hours of use Slim profile design easily adopts into versatile application environment, wall mountable housing for easy and varied installation requirements
