Panduit P06B03M Horizontal Basic Power Distribution Unit
Manufacturer: Panduit
UPC: 613056263383
SKU: P06B03M
Condition: New
Panduit P06B03M Horizontal Basic Power Distribution Unit
Product TypePDU
Brand NamePanduit
ManufacturerPANDUIT CORP
Product ModelP06B03M
Product NameP06B03M Horizontal Basic Power Distribution Unit
Product LineSmartZone
Manufacturer Part NumberP06B03M
Manufacturer Website Addresshttp://www.panduit.com
Packaged Quantity1
Environmentally FriendlyYes
Environmental CertificationRoHSREACH
Output Voltage Range120 V AC to 240 V AC
Power Rating (VA)17.30 kVA
Input Current60 A
Input Voltage230 V AC
Output Voltage208 V AC
Mounting OrientationHorizontal
PlacementRack
Height1.7"
Width17.5"
Depth7.8"
Rack Height1U
Form FactorRack-mountable
Input ReceptaclesIEC 60309 460P9
Output Receptacles6 x IEC 60320 C19
Protection TypeDouble Pole
Limited Warranty3 Year
Panduit Basic Rack PDUs provide reliable and cost effective power distribution in a variety of inputs (Single or Three Phase; Delta or WYE) and outlet configurations (IEC C13, C19, or NEMA compliant). These Rack PDUs have some of the highest outlet densities and the smallest form factors available in the marketplace. They feature up to 48 outlets and come standard with a 10-foot (3 meter) input power cord. They are capable of mounting vertically (0U) or horizontally (1U or 2U) in a data center/enterprise cabinet or rack using standard mounting buttons or included hardware.
