MSI A520VECTWIFI MAG Desktop Motherboard
Manufacturer: MSI
UPC: 824142225226
SKU: A520VECTWIFI
Condition: New
MSI A520VECTWIFI MAG Desktop Motherboard
Specifications
Product Type Desktop Motherboard
Brand Name MSI
Manufacturer MSI
Product Model A520M VECTOR WIFI
Product Name MAG A520M VECTOR WIFI Desktop Motherboard
Product Line MAG
Manufacturer Part Number A520VECTWIFI
Manufacturer Website Address http://www.msi.com
Chipset Manufacturer AMD
Processor Socket Socket AM4
Processor Supported Ryzen 3 Ryzen 5 Ryzen 7 Ryzen 9 Ryzen 3 PRO Ryzen 5 Pro Ryzen 7 PRO
Total Processor Supported 1
Number of Memory Slots 2
Memory Form Factor DIMM UDIMM
Memory Speed Supported 1866 MHz 2133 MHz 2400 MHz 2667 MHz 2800 MHz 2933 MHz 3000 MHz 3066 MHz 3200 MHz 2667 MHz (O.C.) 2800 MHz (O.C.) 2933 MHz (O.C.) 3000 MHz (O.C.) 3066 MHz (O.C.) 3200 MHz (O.C.) 3466 MHz (O.C.) 3600 MHz (O.C.) 3733 MHz (O.C.) 3866 MHz (O.C.) 4000 MHz (O.C.) 4133 MHz (O.C.) 4266 MHz (O.C.) 4400 MHz (O.C.) 4600 MHz (O.C.)
Memory Technology DDR4 SDRAM
Maximum Memory 64 GB
Audio Channels 7.1
Bluetooth Yes
Gigabit Ethernet Yes
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11ac
Number of SATA Interfaces 4
Total Number of Onboard USB Ports 6
Number of Onboard USB 2.0 Ports 4
Number of M.2 Interfaces 1
Number of Onboard USB 3.2 Ports 2
Number of PCI Express x1 Slots 2
Number of Total Expansion Slots 3
Number of PCI Express x16 Slots 1
Total Number of PCI Express Slots 3
Onboard Video CPU Dependent Video
RAID Supported Yes
RAID Levels 0 1 10
Controller Type Serial ATA/600
HDMI Yes
Number of Network (RJ-45) Ports 1
DisplayPort Yes
Total Number of USB Ports 6
Number of USB 2.0 Ports 2
Number of USB 3.2 Ports 4
Country of Origin China
Package Contents
  • MAG A520M VECTOR WIFI Desktop Motherboard
  • Quick Installation Guide
  • MSI Case Badge
  • 2 x SATA Cables
  • Product Registration Card
  • Driver DVD
  • I/O Shielding
  • User Manual
  • Wi-Fi Antenna
Width 9.6"
Depth 8.3"
Form Factor Micro ATX
Limited Warranty 3 Year
Description
The MAG A520M was born through rigorous quality testing and designed to be a symbol of sturdiness and durability. Focused on providing the best user experience, the MAG series has a simple installation process coupled with a friendly user interface making it the best choice for entry level gamers.
