Mellanox MCX556M-ECAT-S25 ConnectX-5 Infiniband/Ethernet Host Bus Adapter
Manufacturer: Mellanox
UPC: 818254539333
Condition: New
Mellanox MCX556M-ECAT-S25 ConnectX-5 Infiniband/Ethernet Host Bus Adapter
Product TypeInfiniband/Ethernet Host Bus Adapter
Brand NameMellanox
ManufacturerMellanox Technologies Ltd
Product NameConnectX-5 Infiniband/Ethernet Host Bus Adapter
Product LineConnectX-5
Manufacturer Part NumberMCX556M-ECAT-S25
Manufacturer Website Addresshttp://www.mellanox.com
Number of Total Expansion Slots2
Expansion Slot TypeQSFP28
Environmentally FriendlyYes
Environmental CertificationRoHS-6
Package Contents
  • ConnectX-5 Infiniband/Ethernet Host Bus Adapter
  • 25cm Harness
  • Short Bracket
Card HeightLow-profile
Form FactorPlug-in Card
Total Number of InfiniBand Ports2
Data Transfer Rate100 Mbit/s
Host InterfacePCI Express 3.0 x8
ConnectX-5 Socket Direct with Virtual Protocol Interconnect® supports two ports of 100Gb/s InfiniBand and Ethernet connectivity, very low latency, and very high message rate, OVS and NVMe over Fabric offloads, providing the highest performance and most flexible solution for the most demanding applications and markets: Machine Learning, Data Analytics, and more. SOCKET DIRECT ConnectX-5 Socket Direct provides 100Gb/s port speed even to servers without x16 PCIe slots by splitting the 16-lane PCIe bus into two 8-lane buses, one of which is accessible through a PCIe x8 edge connector and the other through a parallel x8 Auxiliary PCIe Connection Card, connected by a dedicated harness. Moreover, the card brings improved performance to dual-socket servers by enabling direct access from each CPU in a dual-socket server to the network through its dedicated PCIe x8 interface. In such a configuration, Socket Direct also brings lower latency and lower CPU utilization. The direct connection from each CPU to the network means the Interconnect can bypass a QPI (UPI) and the other CPU, optimizing performance and improving latency. CPU utilization is improved as each CPU handles only its own traffic and not traffic from the other CPU. Socket Direct also enables GPUDirect® RDMA for all CPU/GPU pairs by ensuring that all GPUs are linked to CPUs close to the adapter card, and enables Intel® DDIO on both sockets by creating a direct connection between the sockets and the adapter card. Mellanox Multi-Host™ technology, which was first introduced with ConnectX-4, is enabled in the Mellanox Socket Direct card, allowing multiple hosts to be connected into a single adapter by separating the PCIe interface into multiple and independent interfaces. HPC ENVIRONMENTS ConnectX-5 delivers high bandwidth, low latency, and high computation efficiency for high performance, data intensive and scalable compute and storage platforms. ConnectX-5 offers enhancements to HPC infrastructures by providing MPI and SHMEM/PGAS and Rendezvous Tag Matching offload, hardware support for out-of-order RDMA Write and Read operations, as well as additional Network Atomic and PCIe Atomic operations support. ConnectX-5 VPI utilizes both IBTA RDMA (Remote Data Memory Access) and RoCE (RDMA over Converged Ethernet) technologies, delivering low-latency and high performance. ConnectX-5 enhances RDMA network capabilities by completing the Switch Adaptive-Routing capabilities and supporting data delivered out-of-order, while maintaining ordered completion semantics, providing multipath reliability and efficient support for all network topologies including DragonFly and DragonFly+. ConnectX-5 also supports Burst Buffer offload for background checkpointing without interfering in the main CPU operations, and the innovative transport service Dynamic Connected Transport (DCT) to ensure extreme scalability for compute and storage systems.
