Geist NS30036L 24-Outlets PDU
Manufacturer: Geist
SKU: NS30036L
Condition: New
Geist NS30036L 24-Outlets PDU
Product TypePDU
Brand NameGeist
Product ModelMNS3EGB1-24PBB3-3PS56B0A10-S-A
Product NameMNS3EGB1-24PBB3-3PS56B0A10-S-A 24-Outlets PDU
Manufacturer Part NumberNS30036L
Manufacturer Website Addresshttp://www.vertivco.com
Environmentally FriendlyYes
Environmental CertificationRoHS
Country of OriginUnited States
Package Contents
  • MNS3EGB1-24PBB3-3PS56B0A10-S-A 24-Outlets PDU
  • Vertical Mounting Bracket Kit
Network (RJ-45)Yes
Mounting OrientationVertical
Rack Height0U
Form FactorRack-mountable
Power Rating (Watt)16.60 kW
Input Voltage Range200 V AC - 240 V AC346 V AC - 415 V AC
Input Current30 A
Input Voltage230 V AC
Output Voltage230 V AC
Input Receptacles1 x IEC 60309 30A 3P+N+E
Output Receptacles12 x IEC 60320 C1312 x IEC 60320 C19
Protection TypeOvercurrent ProtectionSingle Pole
  • DHCP
  • HTTP
  • IPv4
  • IPv6
  • LDAP
  • NTP
  • RSTP
  • SSH
  • SMTP
  • SNMP (v1/v2c/v3)
  • Syslog
Limited Warranty5 Year
The NS30036L provides IP-based monitoring and outlet control with quick access to real-time power metrics and environmental sensor data. Using Visible Light Communication (VLC) technology, NS30036L optically transmits power usage data from its LED display to a handheld device using the Geist Mobile App, presenting comprehensive power usage data down to the phase and circuit levels. With the Geist Upgradeable hot-swap technology, users may easily upgrade PDUs to the latest available technology by replacing the Interchangeable Monitoring Device (IMD) module.
