Geist 11656VH rPDU 10-Outlets PDU
Manufacturer: Geist
SKU: 11656VH
Condition: New
Geist 11656VH rPDU 10-Outlets PDU
Product Type PDU
Product Series rPDU
Brand Name Geist
Manufacturer Vertiv
Product Model BRAN100-1025TL
Product Name rPDU BRAN100-1025TL 10-Outlets PDU
Manufacturer Part Number 11656VH
Manufacturer Website Address http://www.vertiv.com/
Environmentally Friendly Yes
Environmental Certification RoHS
TAA Compliant Yes
Country of Origin United States
Package Contents
  • rPDU BRAN100-1025TL 10-Outlets PDU
  • Flush Mount
Mounting Orientation Horizontal
Placement Rack Cabinet
Height 1.7"
Width 17"
Depth 4.5"
Form Factor Rack-mountable Flush-mountable
Power Rating (Watt) 1900 W
Input Voltage Range 100 V AC - 120 V AC
Input Current 20 A
Input Voltage 120 V AC
Output Voltage 120 V AC
Input Receptacles 1 x NEMA L5-20P
Output Receptacles 10 x NEMA 5-20R
Protection Type Overcurrent Protection Thermal Protection
Limited Warranty 5 Year
Metered rPDUs deliver reliable power to critical IT equipment within a rack or cabinet. Includes a local LED display to view real-time power data. Benefits Avoid accidental overloads when deploying or moving critical server equipment with instant access to power consumption metrics on the local digital display. The local LED display provides real-time power data for instant feedback when deploying or moving critical IT equipment. Every unit is 100% tested for reliability and functionality. Simple and convenient configuration options for cord lengths and chassis colors. Standard three-year warranty, upgraded to a five-year warranty with product registration.
