Electro-Voice ZX5-90W Speaker Zx5-90
Manufacturer: Electro-Voice
Mfg Number: Zx5-90
UPC: 701001020980
SKU: ZX5-90W
Condition: New
Electro-Voice ZX5-90W Speaker Zx5-90
Price $864.53
Product TypeSpeaker
Product SeriesZx5
Brand NameElectro-Voice
ManufacturerThe Bosch Group
Product ModelZx5-90
Product NameZx5-90 Speaker
Manufacturer Part NumberZX5-90W
Manufacturer Website Addresshttp://www.bosch.com
Form FactorCeiling MountableStand MountableWall Mountable
Weight (Approximate)49 lb
Crossover Type2-way
Minimum Frequency Response58 Hz
Maximum Frequency Response18 kHz
RMS Output Power600 W
PMPO Output Power2400 W
Driver Type1" Neodymium Tweeter15" Woofer
Impedance8 Ohm
Sensitivity98 dB
The Electro-Voice Zx5 is the new standard of no compromise audio performance and versatility in a simple to use, compact package.At its heart are the transducers. First is the DVX3150 high performance low frequency transducer. EV used advanced computer aided design techniques to create forced air, directional voice coil cooling for high power and efficiency. Finite element analysis was used to optimize the suspension and magnetic structure for long, linear travel to provide low distortion and greater LF extension. These features and details, such as forged magnetic components and special materials, provide reliability with a 500W power rating in a lightweight transducer. Next is the ND2, a 2-inch voice coil compression driver based on neodymium motor structure to allow for maximum output while reducing size and weight to a minimum. Its precision phasing plug and titanium diaphragm provide better HF performance, while the integral heatsink provides cooling for high power output.
