Eaton EMA334-10 ePDU Managed 24-Outlet PDU
Manufacturer: Eaton
UPC: 743172079190
SKU: EMA334-10
Condition: New
Eaton EMA334-10 ePDU Managed 24-Outlet PDU
Product TypePDU
Product SeriesManaged
Brand NameEaton
ManufacturerEaton Corporation
Product ModelEMA334-10
Product NameePDU Managed EMA334-10 24-Outlet PDU
Product LineePDU
Manufacturer Part NumberEMA334-10
Manufacturer Website Addresshttp://www.eaton.com/EatonCom/Markets/NorthAmerica
Network (RJ-45)Yes
Height63.1"
Width2.1"
Depth2.6"
Rack Height36U
Form FactorVertical Rackmount
Power Rating5.76 kVA
Input Current16 A
Input Voltage120 V AC230 V AC
Output Voltage120 V AC
Input Receptacles1 x NEMA L21-20P
Output Receptacles24 x NEMA 5-20R
Package Contents
  • ePDU Managed EMA334-10 24-Outlet PDU
  • ePDU G3 Installation Spare Pack
  • ePDU G3 Network Spare Part Pack
Eaton ePDU G3 Managed technology provides a best-in-class design featuring billing grade accuracy monitoring at the outlet level on a local LCD pixel display or over a network connection. The high accuracy meter will measure current, voltage, power and energy for load balancing, capacity planning, efficiency monitoring and energy usage reporting. Outlet switching allows for on, off or reboot of individual outlets, which reduces the cost of managing remote or local IT data center environments. The robust design is UL rated to operate at 140 degrees F (60 degrees C) ambient operating temperature for containment and high temperature environments. Outlet switching for on, off and reboot control to reduce management costs Outlet level metering to +/- 1% billing grade accuracy for customer billing or level 3 PUE calculations LCD pixel display with hot-swap capability enables load balancing and local setup of key parameters such as IP address and display orientation High operating temperature (140 degrees F / 60 degrees C) for containment or hot network closet environments Daisy chain of IP addresses allows four devices to share one network connection to reduce network install costs by up to 75% 120 volt power distribution to 5-20R outlets which accept standard 5-15P wall plug
