Cisco SP-ATLAS-IHVP= Atlas Sound Speaker IHVP
Manufacturer: Cisco
Mfg Number: IHVP
UPC: 882658231810
SKU: SP-ATLAS-IHVP=
Condition: New
Cisco SP-ATLAS-IHVP= Atlas Sound Speaker IHVP
Product TypeSpeaker
Brand NameCisco
ManufacturerCisco Systems, Inc
Product ModelIHVP
Product NameAtlas Sound IHVP Speaker
Manufacturer Part NumberSP-ATLAS-IHVP=
Manufacturer Website Addresshttp://www.cisco.com
Height10.8"
Width10.8"
Depth4.9"
ColorWhiteGray
Form FactorFlush MountSurface Mount
Minimum Frequency Response600 Hz
Maximum Frequency Response14 kHz
RMS Output Power15 W
Driver Type5.63"
Impedance8 Ohm
Sensitivity120 dB
Model IHVP from Atlas Sound consists of a factory assembled horn loudspeaker/baffle with PCB amp/control board securely mounted to the rear of the baffle via concealed weld studs.The amp/control board is capable of producing 9 Watts RMS into the 8 Ohm loudspeaker with 9VDC minimum power provided by IEEE 802.3 AF compliant POE switches (local 12-18VDC PSU's may also be used instead of POE switches). Interconnection is via a board mounted female RJ-45 connector.The industry standard APF-15 loudspeaker used in the IHVP is a highly efficient 15 Watt compression driver with a proven record of outstanding service reliability. A double re-entrant design provides superior audibility of voice and tone signaling.
