Black Box LGC325A-R3 MultiPower Miniature Transceiver/Media Converter
Manufacturer: Black Box
UPC: 822088149002
Condition: New
Black Box LGC325A-R3 MultiPower Miniature Transceiver/Media Converter
Product Type Transceiver/Media Converter
Brand Name Black Box
Manufacturer Black Box Corporation
Product Name MultiPower Miniature Transceiver/Media Converter
Product Line Multipower Miniature
Manufacturer Part Number LGC325A-R3
Manufacturer Website Address http://www.blackbox.com
Environmentally Friendly Yes
Environmental Certification WEEE RoHS
TAA Compliant Yes
Package Contents
  • MultiPower Miniature Transceiver/Media Converter
  • DIN Rail Mounting Clips
  • AC Power Adapter
Ethernet Technology Gigabit Ethernet
Network Technology 1000Base-T 1000Base-X
Number of Network (RJ-45) Ports 1
Network (RJ-45) Yes
Number of SC Ports 1
Total Number of Ports 2
SC Port Type Simplex
Media Type Supported Optical Fiber Twisted Pair
Fiber Mode Supported Single-mode
Maximum Distance Supported 6.21 Mile
Height 0.8"
Width 1.8"
Depth 3.4"
Form Factor DIN Rail Mountable Rack-mountable
Power Source AC/DC
Limited Warranty 6 Year
The 10-/100-/1000-Mbps copper port auto negotiates speed. Single-Strand Fiber Industrial MultiPower Media Converters seamlessly and transparently convert 10-/100-/1000-Mbps copper to 1000-Mbps fiber. Because these models use only a single strand of fiber, you save on fiber infrastructure! As Layer 2 media converters, they automatically sense and adapt to speed on the copper side for truly plug-and-play operation. Pair this converter with the LGC324A-R3 model to extend your network over fiber at distances up to 10 kilometers (6.2 mi.) on single-mode cable. Single-strand models enable you to both send and receive over one strand of fiber by using different wavelengths in each direction. Industrial MultiPower Media Converters are designed for use in harsh industrial environments. When used with DC power, the converters support an extended temperature range of -13 to +185° F (-25 to +85° C), making them suitable for a wide range of industrial applications. In all, there are three different ways to power the converter: with its AC adapter, using 5 - 50-VDC terminal block power, or via an optional USB Power Adapter Cable.You can even use multiple power options at the same time to provide maximum redundancy and ensure that your mission-critical applications remain up and running. Then, if any one of these power sources fails, the other sources will continue to supply power to the converter seamlessly.The converter comes with a DIN clip for DIN rail mounting. When installing multiple Industrial MultiPower Media Converters on a DIN rail, use one DC input source, then cascade from one DC block to the next until you reach the maximum current available.
