Black Box LES431A LES400 Device Server
Manufacturer: Black Box
UPC: 822088107163
SKU: LES431A
Condition: New
Black Box LES431A LES400 Device Server
Product TypeDevice Server
Product SeriesLES400
Brand NameBlack Box
ManufacturerBlack Box Corporation
Product NameLES400 Device Server
Manufacturer Part NumberLES431A
Manufacturer Website Addresshttp://www.blackbox.com
Network Standard10/100Base-TX
Ethernet TechnologyFast Ethernet
Environmentally FriendlyYes
Environmental CertificationRoHSWEEE
TAA CompliantYes
Country of OriginUnited States
Number of Network (RJ-45) Ports1
Network (RJ-45)Yes
Serial PortYes
Number of Serial Ports1
Media Type SupportedTwisted Pair
Height1.2"
Width3.2"
Depth4.7"
Form FactorDIN Rail Mountable
Weight (Approximate)4.80 oz
Input Voltage Range10 V DC - 58 V DC
Limited Warranty5 Year
UL® Listed for use in Class 1 Division 2 hazardous areas. NEMA TS-2 rated for use in transportation applications. Routes Modbus traffic based on Modbus ID, and remaps conflicting Modbus IDs. Offers Modbus messaging priority control, selectable by source or function code. Features a built-in Web server and easy-to-use management software. Can be easily integrated into most Modbus network configurations. Converts ASCII to RTU as well as ASCII or RTU to Modbus TCP. Features a DB9 port and terminal block for serial connections. Equipped with a 10-/100-Mbps port for TCP connectivity. Boasts high throughput with low latency. Slim IP30 enclosure saves you on DIN rail space. Includes a DIN mounting clip and spring. Easily integrate an older serial Modbus device into your Ethernet Modbus network. This rugged serial server gives you a simple way to migrate to an Ethernet-based industrial control system-without having to replace the older Modbus equipment you've already invested in. Translating older and newer protocols, the 1-Port Modbus Hardened Serial Server converts mismatched serial baud rates and settings, enabling the serial Modbus device to become a node on your Ethernet network. Older PLCs can then talk to newer sensors, meters, scales, and other industrial monitoring and automation instruments. Configuration can be done through a direct serial connection or via the network, so you can improve productivity and cut down on the amount of time required to troubleshoot a serial device on a factory floor or in a remote location. Configure devices, upgrade firmware, and more-all this from the comfort of your office. A simple-to-install, user-friendly software application enables programming. No time-consuming setup is required. The software also features Modbus messaging priority control and allows management through mUL®tiple TCP/IP client sessions. The serial server can be configured for TCP client or server operation.A built-in traffic monitor provides instant verification of a successfUL® installation, and you can view the serial server's operational status in real time. The 1-Port Modbus Hardened Serial Server has a standard DB9 serial port for RS-232 device connections and a removable terminal block for an RS-422 or RS-485 device connection. It also has an autodetecting 10BASE-T/100BASE-TX port for the Ethernet network connection. Either device on either side can be a Modbus master or slave, customizable to your application. A serial master can be configured to control an IP slave, for instance. Also, a serial slave device can be accessed over a LAN or WAN by up to 16 simUL®taneous Modbus TCP masters.
