Black Box ICD300A Industrial Ethernet Surge Protector, DIN Rail
Manufacturer: Black Box
UPC: 0822088075462
SKU: ICD300A
Condition: New
Black Box ICD300A Industrial Ethernet Surge Protector, DIN Rail
Product TypeSurge Suppressor/Protector
Brand NameBlack Box
ManufacturerBlack Box Corporation
Product NameIndustrial Ethernet Surge Protector, DIN Rail
Manufacturer Part NumberICD300A
Manufacturer Website Addresshttp://www.blackbox.com
Green CompliantYes
Green Compliance Certificate/AuthorityRoHS
Country of OriginUnited States
Height5"
Width3.3"
Depth1.6"
Dataline ProtectionEthernet
This single-port, industrial-strength Ethernet surge protector brings data line protection to 10-/100-Mbps links on plant floors and in other harsh areas. The durable DIN mount protector suits temperatures ranging from -40 to +176? F (-40 to +80° C) and is designed to protect all eight pins of standard CAT5e cabling. Use this compact device alongside other CAT5e cabled DIN rail equipment, such as hardened switches, media converters, and repeaters. Protecting 10BASE-T or 100BASE-TX connections from transient surges, the surge protector doesn't degrade data signals as they pass through. And it works in Power over Ethernet (PoE) applications, too. The 802.11af-compatible surge protector supports both PoE operating modes: Mode A, with power applied to the data pairs (Pins 1/2 and Pins 3/6) and Mode B, with power applied to the unused pairs (Pins 4/5 and Pins 7/8).
