B+B 856-30600 1000 Mbps Compact 3 Port Media Converter
Manufacturer: B+B
UPC: 0641676193346
SKU: 856-30600
Condition: New
B+B 856-30600 1000 Mbps Compact 3 Port Media Converter
Product TypeTransceiver/Media Converter
Brand NameB+B
ManufacturerB+B SmartWorx
Product Model856-30600
Product Name1000 Mbps Compact 3 Port Media Converter
Product LineGiga-McBasic-II
Manufacturer Part Number856-30600
Manufacturer Website Addresshttp://www.bb-elec.com
Green CompliantYes
Green Compliance Certificate/AuthorityWEEERoHS
Ethernet TechnologyGigabit Ethernet
Network Technology1000Base-TX1000Base-X
Number of Total Expansion Slots1
Number of SFP Slots1
Expansion Slot TypeSFP
USBNo
DVINo
Network (RJ-45)Yes
Management PortNo
Total Number of Ports2
Media Type SupportedTwisted PairOptical Fiber
Height1.3"
Width4.2"
Depth4.8"
Form FactorDesktop
Power SourcePower Supply
Limited WarrantyLifetime
The McBasic's small, table-top design and durability make it perfect for installation anywhere space is limited. Additionally, the McBasic comes with an internal AC power supply. This feature significantly increases reliability over products that use bulky, external AC/DC power transformers. The unmanaged, stand-alone device offers two 10/100/1000Mbps copper ports and one fiber port, available in fixed fiber or SFP form factor.Link Fault Pass Through (LFPT), a diagnostic feature available via a DIP Switch, make isolating fiber breaks easier, should they occur. The McBasic also features AutoCross to support crossover/pass-through on the twisted pair connection and diagnostic LEDs. Most McBasic units are available with dual or Single Strand fiber, as well as a model with an SFP cage, to support any fiber type.
