Aten VE901R DisplayPort HDBaseT-Lite Receiver (4K@40m; 1080p@70m)
Manufacturer: Aten
UPC: 818275276262
SKU: VE901R
Condition: New
Aten VE901R DisplayPort HDBaseT-Lite Receiver (4K@40m; 1080p@70m)
Price $162.07
Product TypeVideo Extender Transmitter
Brand NameAten
ManufacturerAten Technologies
Product ModelVE901R
Product NameDisplayPort HDBaseT-Lite Receiver (4K@40m; 1080p@70m)
Product LineVanCryst
Manufacturer Part NumberVE901R
Manufacturer Website Addresshttp://www.aten-usa.com
Graphics Modes4K
Maximum Video Resolution4096 x 2160
Environmentally FriendlyYes
Environmental CertificationRoHSWEEE
Package Contents
  • DisplayPort HDBaseT-Lite Receiver (4K@40m; 1080p@70m)
  • 1 x Power Adapter
  • 1 x User Instructions
Twisted Pair Cable StandardCategory 6a
Media Type SupportedTwisted Pair
Maximum Operating Distance229.66 ft
Number of Output Devices Supported1
Connectivity TechnologyWired
Number of Network (RJ-45) Ports1
Network (RJ-45)Yes
DisplayPortYes
Height1.1"
Width2.6"
Depth3.7"
Form FactorRack-mountable
Weight (Approximate)9.52 oz
The VE901R DisplayPort HDBaseT-Lite Receiver is able to extend a DisplayPort display up to 70 m using a Cat 6/6a/ATEN 2L-2910 Cat 6 cable. This combination of ATEN and HDBaseT™ technology supports sharing 4K media up to 40 m away, offering a simple, adaptable, and cost-effective solution for any professional A/V installation. The VE901R DisplayPort HDBaseT-Lite Receiver is the perfect choice for professional A/V installations that require video signal interference protection, such as in medical and military installations. With its lightweight and easy-to-mount design, and a slip-resistant DC Jack lock mechanism, the VE901R can be installed in a multitude of locations while ensuring peace of mind with its reliability.
