Aten VE1812T HDMI HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A)
Manufacturer: Aten
UPC: 672792007682
SKU: VE1812T
Condition: New
Aten VE1812T HDMI HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A)
Price $210.47
Product TypeVideo Extender Transmitter
Brand NameAten
ManufacturerAten Technologies
Product ModelVE1812T
Product NameHDMI HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A)
Product LineVanCryst
Manufacturer Part NumberVE1812T
Manufacturer Website Addresshttp://www.aten-usa.com
Graphics Modes4K
Maximum Video Resolution4096 x 2160
Environmentally FriendlyYes
Environmental CertificationRoHSWEEE
Package Contents
  • HDMI HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A)
  • 1 x Power Adapter
  • 1 x RS-232 Terminal Block
  • 1 x User Instructions
Twisted Pair Cable StandardCategory 6a
Media Type SupportedTwisted Pair
Maximum Operating Distance492.13 ft
Number of Input Devices Supported1
Connectivity TechnologyWired
Number of Network (RJ-45) Ports1
Network (RJ-45)Yes
Serial PortYes
Number of HDMI Inputs1
HDMI InYes
Height1.2"
Width4.8"
Depth5.5"
ColorBlack
Form FactorRack-mountable
Weight (Approximate)1.04 lb
Limited Warranty2 Year
The VE1812T features Power over HDBaseT (POH) which sends power from Tx to Rx over Cat 5e / 6 / 6a cable without any additional power supply. The VE1812T supports RS-232 and IR signaling pass-through, allowing you to control the HDMI source device from the receiver unit (VE1812R) while also accessing the HDMI display device from the transmitter unit (VE1812T). The IR signals can also be extended in both directions. The VE1812T HDMI HDBaseT Transmitter with POH is HDMI (3D, Deep Color, 4kx2k) and HDCP compatible. When transmitting HDMI / 4K with a Cat 6a or ATEN 2L-2910 Cat 6 cable, the maximum distance can reach up to 100 meters. With Long Reach Mode enabled, the VE1812T can extend HDMI signal up to 150m @1080p. The VE1812T is perfect for digital classrooms, video conference rooms, gaming or any installation that requires superior video quality.
