Aten VM3909H VM3404H HDMI HDBaseT-Lite Matrix Switch
Manufacturer: Aten
UPC: 672792006654
SKU: VM3909H
Condition: New
Aten VM3909H VM3404H HDMI HDBaseT-Lite Matrix Switch
Product TypeAudio/Video Switchbox
Brand NameAten
ManufacturerAten Technologies
Product ModelVM3909H
Product NameVM3404H HDMI HDBaseT-Lite Matrix Switch
Product LineVanCryst
Manufacturer Part NumberVM3909H
Manufacturer Website Addresshttp://www.aten-usa.com
Graphics Modes4K
Maximum Video Resolution4096 x 2160
Green CompliantYes
Green Compliance Certificate/AuthorityWEEERoHS
Package Contents
  • VM3909H HDMI HDBaseT-Lite Matrix Switch
  • 1 x Power Cord
  • 1 x Mounting Kit
  • 1 x User Instructions
Maximum Operating Distance229.66 ft
Media Type SupportedTwisted Pair
Number of HDMI Inputs9
Number of HDMI Outputs9
Connectivity (RJ-45)Yes
Number of Connectivity (RJ-45) Ports10
Number of Displays Supported9
Number of Input Devices Supported9
Connectivity TechnologyCable
Device SupportedDisplay
Weight (Approximate)16.16 lb
VM3909H 9 x 9 HDMI HDBaseT-Lite Matrix SwitchWith the rapid development of HDBaseT technology, ATEN has released the new VM3909H HDMI HDBaseT-Lite Matrix Switch. The switch extends uncompressed 4K / Full HD digital video, audio, IR and power via HDBaseT technology through a single Cat 6a cable up to 40/70 meters. When the VM3909H is combined with VE805R receivers, it supports both ATEN Seamless Switch™ technology and Video Wall functionality. ATEN's exclusive Seamless Switch™ technology employs an FPGA graphics processor to ensure continuous video streaming, real-time control and stable signal transmission across all sources. The Video Wall functionality allows you to create 18 video wall profiles for custom screen layouts through an easy-to-use web interface. The Power over HDBaseT (POH) feature provides an ingenious way to power the VE802R receivers through the Cat 5e cable without the need of using an additional power supply.
