Product Type | Isolation Transformer |
---|
Brand Name | APC |
---|
Manufacturer | American Power Conversion Corp |
---|
Product Name | 20kVA Isolation Rack-mountable Transformer |
---|
Manufacturer Part Number | APTF20KW01 |
---|
Manufacturer Website Address | http://www.apc.com |
---|
Package Contents | - 20kVA Isolation Transformer
- Documentation CD
- Hardwire panel
- Installation guide
- Rack Mounting brackets
- User Manual
|
---|
Height | 6.9" |
---|
Width | 17" |
---|
Depth | 29.8" |
---|
Form Factor | Rack-mountable |
---|
Weight (Approximate) | 260 lb |
---|
Current | 100 A Total Current Draw Per Phase100 A Line Current Per Phase100 A Input Current Per Phase |
---|
Input Voltage | 110 V AC220 V AC |
---|
Output Voltage | 100 V AC Nominal120 V AC Nominal200 V AC Nominal208 V AC Nominal230 V AC Nominal |
---|
Power Rating | 20 kVA |
---|
Input Receptacles | Hard Wire 3-wire (2PH + G)Hard Wire 3 wire (1PH+N+G)Hard Wire 4-wire (2PH+N+G) |
---|
Output Receptacles | 1 x Hard Wire 3-wire (2PH + G)1 x Hard Wire 3-wire (H N + G)1 x Hard Wire 4-wire (2PH+N+G) |
---|
Limited Warranty | 2 Year |
