APC ACF002 Rack Air Distribution System
Manufacturer: APC
UPC: 731304120827
SKU: ACF002
Condition: New
APC ACF002 Rack Air Distribution System
Price $1,003.03
Product TypeAirflow Cooling System
Brand NameAPC
ManufacturerAmerican Power Conversion Corp
Product ModelACF002
Product NameACF002 Rack Air Distribution System
Manufacturer Part NumberACF002
Manufacturer Website Addresswww.apc.com
Package Contents
  • ACF002 Rack Air Distribution System
  • Rack Mounting Brackets
  • User Manual
  • Height3.5"
    Width1.7"
    Depth2.9"
    ColorBlack
    Form FactorRack-mountable
    Weight (Approximate)41.09 lb
    Power Consumption230 W
    Input Voltage230 V AC
    Receptacle TypeIEC 60320 C14
    Maximum Air Flow420 CFM
    Limited Warranty2 Year
    The Rack Air Distribution Unit is a 2U fan unit that connects into the raised floor and pulls supply air directly into the enclosure. This prevents the conditioned air from mixing with warmer room air before reaching the equipment. This minimizes temperature differences between the top and bottom of the enclosure, while also preventing hot exhaust air recirculation to the inlet of the enclosure. The product is recommended for rack enclosures with loads greater than 1.5kW and can provide airflow for loads up to 3.5kW. It is also ideal for enclosures in raised floor environments where underfloor air distribution is inadequate.
