Advantech EKI-1522-CE 2-port RS-232/422/485 Serial Device Server
Manufacturer: Advantech
SKU: EKI-1522-CE
Condition: New
Advantech EKI-1522-CE 2-port RS-232/422/485 Serial Device Server
Product Type Device Server
Brand Name Advantech
Manufacturer Advantech Co., Ltd
Product Model EKI-1522
Product Name 2-port RS-232/422/485 Serial Device Server
Manufacturer Part Number EKI-1522-CE
Manufacturer Website Address http://www.advantech.com
Network Standard 10/100Base-TX
Ethernet Technology Fast Ethernet
Environmentally Friendly Yes
Environmental Certification RoHS
Number of Network (RJ-45) Ports 2
Network (RJ-45) Yes
Serial Port Yes
Number of Serial Ports 2
Media Type Supported Twisted Pair
Height 5.5"
Width 1.4"
Depth 3.7"
Form Factor Wall Mountable DIN Rail Mountable
Weight (Approximate) 1.04 lb
Input Voltage Range 12 V DC - 48 V DC
Power Consumption 3.20 W
Limited Warranty 5 Year
EKI-1521, EKI-1522 and EKI-1524 feature two independent Ethernet ports and MAC addresses to provide a redundant network mechanism to guarantee Ethernet network reliability. EKI-1521, EKI-1522 and EKI-1524 are serial device servers that connect RS-232/422/485 serial devices, such as PLC, meters, sensors, and barcode reader to an IP-based Ethernet LAN. They allow nearly any device with serial ports to connect and share an Ethernet network. EKI-1521, EKI-1522 and EKI-1524 provide various operations: COM port redirection (Virtual COMport), TCP Server, TCP Client and UDP mode. With COM port redirection mode, standard serial operation calls are transparently redirected to the EKI-1521, EKI-1522 and EKI-1524, guaranteeing compatibility with legacy serial devices and enabling backward compatibility with existing software. With TCP server, TCP client, and UDP modes, EKI- 1521, EKI-1522 and EKI-1524 ensure the compatibility of network software that uses a standard network API. Moreover, you can make serial devices communicate with other devices peer-to-peer, without any intermediate host PCs and software programming.
